RM0453
9.4.3
IPCC processor 1 status set clear register (IPCC_C1SCR)
Address offset: 0x008
Reset value: 0x0000 0000
Reading this register always returns 0x0000 0000.
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:22 Reserved, must be kept at reset value.
Bits 21:16 CHnS: Processor 1 transmit channel n status set (n = 6 to 1).
Associated with IPCC_C1TOC2SR.CHnF
1: Processor 1 transmit channel n status bit set.
0: No action.
Bits 15:6 Reserved, must be kept at reset value.
Bits 5:0 CHnC: Processor 1 receive channel n status clear (n = 6 to 1).
Associated with IPCC_C2TOC1SR.CHnF
1: Processor 1 receive channel n status bit clear.
0: No action.
9.4.4
IPCC processor 1 to processor 2 status register
(IPCC_C1TOC2SR)
Address offset: 0x00C
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:6 Reserved, must be kept at reset value.
Bits 5:0 CHnF: Processor 1 transmit to processor 2 receive channel n status flag before masking (n = 6
to 1).
1: Channel occupied, data can be read by the receiving processor 2.
Generates a channel RX occupied interrupt to processor 2, when unmasked.
0: Channel free, data can be written by the sending processor 1.
Generates a channel TX free interrupt to processor 1, when unmasked.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
Inter-processor communication controller (IPCC)
24
23
22
Res.
Res.
Res.
CH6S
8
7
6
Res.
Res.
Res.
CH6C
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
CH6F
RM0453 Rev 5
21
20
19
18
CH5S
CH4S
CH3S
rw
rw
rw
rw
5
4
3
2
CH5C
CH4C
CH3C
rw
rw
rw
rw
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
CH5F
CH4F
CH3F
r
r
r
r
17
16
CH2S
CH1S
rw
rw
1
0
CH2C
CH1C
rw
rw
17
16
Res.
Res.
1
0
CH2F
CH1F
r
r
395/1450
