Bit 3 Reserved, must be kept at reset value.
Bits 2:0 LPMS[2:0]: Low-power mode selection for CPU2
Note: If LPR bit is set, Stop 2 mode cannot be selected and Stop 1 mode must be entered
6.6.18

PWR CPU2 control register 3 (PWR_C2CR3)

This register is not reset when exiting Standby modes.
Access: additional APB cycles are needed to access this register versus those needed for a
standard APB access (three for a write and two for a read).
Address offset: 0x084
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
EWRFI
EIWUL Res. Res.
RQ
rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bit 15 EIWUL: internal wake-up line for CPU2 enable
Bit 14 Reserved, must be kept at reset value.
Bit 13 EWRFIRQ: radio IRQ[2:0] wake-up for CPU2 enable
Bit 12 Reserved, must be kept at reset value.
Bit 11 EWRBUSY: radio busy wake-up for CPU2 enable
These bits are not reset when exiting Standby mode.
These bits select the low-power mode entered when CPU2 enters the Deep-Sleep mode.
The system low-power mode entered depends also on the PWR_CR1.LPMS[2:0] allowed
Low-power mode from CPU1.
000: Stop 0 mode
001: Stop 1 mode
010: Stop 2 mode
011: Standby mode
1xx: Shutdown mode
instead of Stop 2.
In Standby mode, SRAM2 is preserved, depending on RRS bit configuration in
control register 3 (PWR_CR3).
28 27 26 25
Res. Res. Res.
12 11 10 9
EWRB
APC Res.
USY
rw rw
0: Internal wake-up line to CPU2 disabled
1: Internal wake-up line to CPU2 enabled
When this bit is set, the radio IRQ[2:0] is enabled and triggers a wake-up from Standby event
to CPU2.
When this bit is set, the radio busy is enabled and triggers a wake-up from Standby event to
CPU2 when a rising or a falling edge occurs. The active edge is configured via the
WRFBUSYP bit in the PWR control register 4
24 23 22
Res. Res. Res.
8 7 6
EWPV
Res. Res.
D
rw
(PWR_CR4).
RM0453 Rev 5
Power control (PWR)
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
EWUP
Res. Res. Res.
3
rw
PWR
17 16
Res. Res.
1 0
EWUP EWUP
2 1
rw rw
