Table -
Tx Power (Continued)
Parameter
Tx Power Level
(1, highest through 5,
lowest)
Tx Power Configuration
Current Tx Power Level
Table -
Physical Channel Parameters
Parameter
Current Channel
Configuration
Current CCA Mode
ED/TI Threshold
Table -
Physical Antenna Parameters
Parameter
Antenna Type
Diversity
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 73
OmniAccess AP 1200 or 1250 transmit power level (1 = Maximum power
allowed per Country Code setting, 2 = 50% power, 3 = 25% power,
4 = 12.5% power, and 5 = 6.25% power).
Note that the power levels and available channels are defined by the
Country Code setting, and are regulated on a country by country basis.
Refer to Alcatel OmniAccess Wireless System Supported Regulatory
Domains in the Alcatel OmniAccess Wireless Product Guide for the
maximum Transmit Power Levels for each country.
Globally controlled or Customized for this OmniAccess AP 1200 or 1250.
Displays the operating transmit power level from the transmit power
table.
Current operating frequency channel.
Locally customized or globally controlled.
CCA method in operation. Valid values are:
• Energy detect only (edonly) = 01,
• Carrier sense only (csonly) = 02,
• Carrier sense and energy detect (edandcs)= 04
• Carrier sense with timer (cswithtimer)= 08
• High rate carrier sense and energy detect (hrcsanded)=16.
The Energy Detect and Threshold being used to detect a busy medium
(frequency). CCA shall report a busy medium upon detecting the RSSI
above this threshold.
Internal
Enabled via the internal antennas or via either Connector A or
Connector B.
802.11b/g AP Interfaces > Details
Description
Description
Description
