2.
Clean up the graphic as desired.
Note:
the bitmap. Colored and/or tinted windows can remain in the graphic, as well as
doors that are normally closed. Reduce all walls to one pixel width to make cleaner
vector graphics.
-
Use the Brightness slider to add or remove bitmap detail.
-
Use the Raster/Connect command to fill in gaps between line segments.
-
Use the Raster/Fill Small Holes (F7) command to fill in gaps between line segments.
-
Use the Raster/Fill Holes (F8) command to fill in large gaps between line segments.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide
All doors that are normally open and clear windows should be removed from
Using the ACS Floor Plan Editor
