Configure Add Switch - Alcatel OmniAccess Wireless System 2.1 Product Manual

title to sort the list items. Click a list item to display parameters for that IP Address. Refer to
Configure <IPaddr> > Switch
•
Switch Name: Click to sort. Name of the of the Alcatel OmniAccess Switch or Appliance.
•
Location: Indicates the location of the Alcatel OmniAccess Switch or Appliance. Click the list
item to reveal a map showing the location of the device. Refer to
•
Software Version: The Alcatel OmniAccess Operating System release.version.dot.maintenance
number of the code currently running on the Alcatel OmniAccess Switch or Appliance.
•
Mobility Group Name: Name of Mobility or WPS Group.
•
Reachability Status: Reachable or Not Reachable.
•
Alarm Status: A colored dot indicating Up (green), Minor Alarm (yellow) or Critical Alarm (red).
Select a command pulldown
•
Add Switch: Adds an Alcatel OmniAccess Switch or Appliance. Refer to
•
Remove Switches: Select an Alcatel OmniAccess Switch or Appliance by clicking the checkbox,
select this command and click GO.
•
Reboot Switches: Select an Alcatel OmniAccess Switch or Appliance by clicking the checkbox,
select this command and click GO.
•
Download Software: Select one or more Alcatel OmniAccess Switches or Appliances by clicking
their checkboxes, select this command and click GO.
•
Save Config to Flash: Save the current configuration to flash memory.
•
View Audit Reports: Refer to
•
GO button.
Left sidebar
Search for Alcatel OmniAccess Switches and Appliances by (pulldown):
•
Networks.
•
IP Address.
•
Switch Name.
•
Select a Network (All Networks, xxx.xxx.xxx.xxx).
•
Search (button).

Configure Add Switch

Use CONFIGURE/Switches and under Select a command, select Add Switch to access this page.
This page allows you to add an Alcatel OmniAccess Switch or Appliance:
•
IP Address: IP address network mask.
Note:
Addresses.
•
Network Mask: Enter the network mask of the new Alcatel OmniAccess Switch or Appliance.
The default value is 255.255.255.0.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 113
Properties.
Configure <IPaddr> > Audit
Configure Add Switch
If the Subnet Mask is set to 0.0.0.0, an IP Address of 0.0.0.0 matches all IP
Monitor Maps >
Configure Add
Reports.
Configure Add Switch
<campus>.
Switch.
