Alcatel OmniAccess Wireless System 2.1 Product Manual page 545

Table -
Current Rules (Continued)
Parameter
Protocol
Source Port
Dest Port
DSCP
Direction
The default filter is to deny all access unless a Rule explicitly permits it.
Note:
•
When the ACL contains one or more ACL Rule, click Edit to modify the rule on the
Control Lists > Rules > Edit
Table -
New Rule Parameters
Parameter
Sequence
Source
Destination
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 96
Protocol to use for this ACL:
• Any - All protocols
• TCP - Transmission Control Protocol
• UDP - User Datagram Protocol
• ICMP - Internet Control Message Protocol
• ESP - IP Encapsulating Security Payload
• AH - Authentication Header
• GRE - Generic Routing Encapsulation
• IP - Internet Protocol
• Eth Over IP - Ethernet over Internet Protocol
• OSPF - Open Shortest Path First
• Other - Any other IANA protocol (http://www.iana.org/)
Any or IP Address and Netmask.
Any or IP Address and Netmask.
Any or Specific (from 0 - 63). Differentiated Services Code Point
(DSCP). A packet header code that can be used to define quality
of service across the Internet.
Any, Inbound (from client) or Outbound (to client).
page.
The operator can define up to 64 Rules for each ACL.
The Rules for each ACL are listed in contiguous sequence from 1
to 64. That is, if Rules 1 through 4 are already defined and you
add Rule 29, it is be added as Rule 5.
Note that if you add or change a Sequence number, the Alcatel
OmniAccess Operating System adjusts the other rule sequence
numbers to retain the contiguous sequence. For instance, if you
have Sequence numbers 1 through 7 defined and change
number 7 to 5, the Alcatel OmniAccess Operating System
automatically reassigns Sequence 6 to 7 and Sequence 5 to 6.
Any or IP Address and Netmask.
Any or IP Address and Netmask.
Access Control Lists > Edit
Description
Description
Access
