Monitor Menu Bar Selection

This menu bar selection provides access to the Alcatel OmniAccess Switch or Appliance and OmniAccess
AP 1200 or 1250 summary details. Use the selector area to access the respective network details.
Making this selection from the menu bar displays the system
The following pages can be accessed from the Monitor Menu Bar Selection:
•
Summary
•
Switch Statistics
•
Ports Statistics
•
Ports > Statistics
•
Third-Party APs
•
Third-Party APs > New
•
Third-Party APs > Edit
•
Rogue APs
•
Rogue AP Detail
•
Rogue Clients
•
Rogue Client Detail
•
Adhoc Rogues
•
Adhoc Rogues > Detail
•
802.11a OmniAccess Radios
•
Radio > Statistics
•
802.11b/g OmniAccess Radios
•
Clients
•
Clients > Detail
•
RADIUS Servers
•
RADIUS Servers > Authentication Stats
•
RADIUS Servers > Accounting Stats
Summary
Summary
Use MONITOR/Summary to navigate to this page.
This summary page provides a top level description of your Alcatel OmniAccess Switch or Appliance.
Configure the parameters listed on this page by selecting the appropriate page from links on the left of
the summary page. The following table describes each of the these read-only fields and is refreshed
every 30 seconds.
Table -
Summary Parameters
Parameter
Network IP Address
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide
Monitor Menu Bar Selection
Local network IP address of the Alcatel OmniAccess Switch or
Appliance as described in Management Interface in the Alcatel
OmniAccess Wireless Product Guide.
Summary page.
Description
Monitor Menu Bar Selection
