Sequence: The operator can define up to 64 Rules for each ACL. The Rules for each ACL are
listed in contiguous sequence from 1 to 64. That is, if Rules 1 through 4 are already defined and
you add Rule 29, it will be added as Rule 5. Note that if you add or change a Sequence number,
Alcatel OmniAccess Operating System adjusts the other rule sequence numbers to retain the
contiguous sequence. For instance, if you have Sequence numbers 1 through 7 defined and
change number 7 to 5, Alcatel OmniAccess Operating System automatically reassigns Sequence
5 to 6 and Sequence 6 to 7.
•
Source: Any or IP Address and Netmask.
•
Destination: Any or IP Address and Netmask.
•
Protocol: Protocol to use for this ACL:
-
Any - All protocols
-
TCP - Transmission Control Protocol
-
UDP - User Datagram Protocol
-
ICMP - Internet Control Message Protocol
-
ESP - IP Encapsulating Security Payload
-
AH - Authentication Header
-
GRE - Generic Routing Encapsulation
-
IP - Internet Protocol
-
Eth Over IP - Ethernet over Internet Protocol
-
OSPF - Open Shortest Path First
-
Other - Any other IANA protocol (http://www.iana.org/)
When TCP or UDP Protocol is selected:
-
Source Port: Source Port. Can be Any, HTTP, HTTPS, Telnet, RADIUS, DHCP Server,
DHCP Client, DNS, L2TP, PPTP control, FTP control, SMTP, SNMP, LDAP, Kerberos,
NetBIOS NS, NetBIOS DS, NetBIOS SS, MS Dir Server, Other and Port Range.
-
Dest Port: Destination port. If TCP or UDP Protocol is selected, can be Any, HTTP,
HTTPS, Telnet, RADIUS, DHCP Server, DHCP Client, DNS, L2TP, PPTP control, FTP
control, SMTP, SNMP, LDAP, Kerberos, NetBIOS NS, NetBIOS DS, NetBIOS SS, MS Dir
Server, Other and Port Range.
•
DSCP: Differentiated Services Code Point. Any, or Specific IP Address.
•
Direction: Any, Inbound, Outbound.
•
Action: Permit, Deny.
Command Buttons
•
Save: Save and return to
•
Cancel
Configure <IPaddr> > Access Control List > Add from Template
Use CONFIGURE/Switches and click an IP address under the IP Address column, on the left sidebar
menu, select Security and click Access Control Lists, under the Select a command pulldown, select
Add Access Control, click GO to access this page.
Note that the Standalone WPS Alcatel OmniAccess Wireless System described in About the Alcatel
OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not support ACLs.
11/5/04 Configure <IPaddr> > Access Control List > Add from Template
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 126
Configure Access Control List > Template <listname> Rules.
