Step 6: Using the Startup Wizard

•
The first time you power up the Alcatel OmniAccess Switch or Appliance with a new factory
Alcatel OmniAccess Operating System software load, use the Startup Wizard to do the
following:
Note:
Information
-
Enter the System (Alcatel OmniAccess Switch or Appliance) Name, up to 32 printable
ASCII characters.
-
Enter the Administrative User Name and Password, each up to 24 printable ASCII
characters. The default Administrative User login and password are admin and admin,
respectively.
Note:
subnets.
-
Enter the Service-Port Interface IP configuration protocol (none, or DHCP). If you do not
want to use the Service port or if you want to assign a static IP Address to the Service
port, enter none.
If you entered none, enter Service-Port Interface IP Address and netmask on the next
two lines. If you do not want to use the Service port, enter 0.0.0.0 for the IP Address
and netmask.
-
Enter the Management Interface (refer to Management Interface in the Alcatel
OmniAccess Wireless Product Guide) IP Address, netmask, default router IP address,
and optional VLAN identifier (a valid VLAN identifier, or '0' for untagged).
-
Network Interface (Distribution System) Physical Port number:
* 4012: 1 - 12 for front panel or 13 for GigE port
* 4024: 1 - 24 for front panel or 25 for GigE port
* 4102: 1 for either front panel GigE port
-
Enter the IP address of the default DHCP Server that will supply IP Addresses to clients,
the Alcatel OmniAccess Switch or Appliance Management Interface, and optionally to
the Service Port Interface.
-
Enter the LWAPP Transport Mode, LAYER2 or LAYER3 (refer to Layer 2 and Layer 3
Operation in the Alcatel OmniAccess Wireless Product Guide).
-
Enter the Virtual Gateway IP Address; one fictitious, unassigned IP address (such as
1.1.1.1) to be used by all Alcatel OmniAccess Wireless System Layer 3 Security and
Mobility managers.
-
Enter the Alcatel Mobility Group (RF Group) Name.
-
Enter the WLAN 1 SSID, or Network Name. This is the default SSID that the
OmniAccess AP Access Points and Alcatel OmniAccess Remote Edge Access Points, or
OmniAccess 1200R APs, broadcast when they associate with the Alcatel OmniAccess
Switch or Appliance.
-
Allow or disallow Static IP Addresses for clients. (Yes = clients can supply their own IP
Address. No = clients must request an IP Address from a DHCP server.)
-
If you are configuring a RADIUS Server now, enter YES, and the RADIUS Server IP
Address, communication port, and Secret. Otherwise, enter NO.
-
Enter the Country Code for this installation. Type 'help' to list the supported countries,
and refer to Configuring the Alcatel OmniAccess Switch or Appliance and Alcatel
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 15
Use the information you collected in
for this Step.
The Service-Port Interface and Management Interface must be on different
