Commands Menu Bar Selection

This menu bar selection provides access to the Alcatel OmniAccess Switch or Appliance Alcatel Omni-
Access Operating System software management commands. Use the selector area to access the Alcatel
OmniAccess Operating System software management data pages. Making this selection from the menu
bar opens the

Download File to Switch

Access the following pages from the Commands Menu Bar Selection:
•
Download File to Switch
•

Upload File from Switch

•
System Reboot
•
System Reboot > Save?
•
System Reboot > Confirm
•
Reset to Factory Default
•
Set Time
Download File to Switch
Use COMMANDS/Download File to navigate to this page.
Use this page to download and install new Alcatel OmniAccess Switch or Appliance Alcatel OmniAccess
Operating System software or a configuration file to your Alcatel OmniAccess Switch or Appliance from
a local TFTP (trivial file transfer protocol) server.
Note:
Control System, because the ACS and the TFTP server use the same communication
port.
•
Select Code to download and automatically install new Alcatel OmniAccess Switch or Appliance
Alcatel OmniAccess Operating System software. This process takes at least three minutes and
overwrites your existing code and configuration. You must reboot the Alcatel OmniAccess
Switch or Appliance after the new Alcatel OmniAccess Operating System software is installed.
•
Select Configuration to download a backup configuration file to the Alcatel OmniAccess Switch
or Appliance.
•
Configure the IP address of the TFTP server, the Maximum Retries, the Timeout (in seconds),
the directory path on the server (default = /), and the name of the file to be transferred.
Command Buttons
•
Clear: Entries in the TFTP data fields are deleted.
•
Download: Begin the download from the TFTP server; you are prompted to continue.
•
Help: Request that the help page be displayed in a new browser window.
Upload File from Switch
Use COMMANDS/Upload File to navigate to this page.
Use this page to upload files from your Alcatel OmniAccess Switch or Appliance to a local TFTP (trivial
file transfer protocol) server. You can upload the following files:
•
Configuration file
•
Event Log
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 122
page.
Download File to Switch
The TFTP server cannot run on the same computer as the Alcatel OmniAccess
Upload File from Switch
