Alcatel OmniAccess Wireless System 2.1 Product Manual page 653

Table -
General (Continued)
Parameter
Primary Switch
Port Number
Map Location
Statistics Timer
Table -
AP Interfaces
Parameter
AP Interfaces
Admin Status
Op Status
Alarm Status
Table -
Versions
Parameter
Software
Boot Version
Table -
Inventory Information
Parameter
AP Model
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 74
This is the OmniAccess AP 1200 or 1250's Primary Alcatel OmniAccess
Switch or Appliance SNMP name. The OmniAccess AP 1200 or 1250 will
attempt to associate with this Alcatel OmniAccess Switch or Appliance first
for all network operations and in the event of a hardware reset.
Port Number: The OmniAccess AP 1200 or 1250 is connected to this
Alcatel OmniAccess Switch or Appliance port.
Customer-definable location name for the OmniAccess AP 1200 or 1250.
Click to look at the actual location on a map. Refer to
<campus> > <building> > <floor area>
<floor area>.
This counter sets the time in seconds that the OmniAccess AP 1200 or
1250 sends its DOT11 statistics to the Alcatel OmniAccess Switch or
Appliance.
These are 802.11a and 802.11b/g OmniAccess Radios. Click a list item to
view the parameters. Refer to
type>.
Displays the administration state of the OmniAccess AP 1200 or 1250 of
either enabled or disabled.
Displays the operational status of the OmniAccess Radio: either UP or
DOWN.
Indicates any pending alarms. Refer to
The Alcatel OmniAccess Operating System release.version.dot.mainte-
nance number of the code currently running on the Alcatel OmniAccess
Switch or Appliance.
Alcatel OmniAccess Operating System bootloader version number.
The Access Point model number.
Description
or Monitor Maps > <building> >
Description
Monitor Access Points > <name> > <radio
Alarm
Description
Description
Monitor Access Points > <name>
Monitor Maps >
Monitor.
