Alcatel OmniAccess Wireless System 2.1 Product Manual page 857

Note:
threads. Do not overtighten the screws, or the bracket will not fit under the screw
heads.
Figure -
Assembling the Mounting Screws and Spring Washers to the OmniAccess AP 1200 or 1250
•
Copy the MAC address(es) from the label(s) on the OmniAccess AP 1200 or 1250 onto the
corresponding location on the map. MAC addresses have the format 000B85xxxxxx.
•
You have already attached the projection-mount L-bracket to the wall in
Mounting Locations.
•
Slide the screws into the keyhole slots on the mounting bracket as shown in the following
figure.
Note:
1200 or 1250 and adjust the screws until they securely hold the bracket.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 14
The OmniAccess AP 1200 or 1250 threaded holes have precision-depth
If the screws do not securely hold the bracket, remove the OmniAccess AP
Step 4: Mounting the OmniAccess AP Access Points
Step 3: Preparing
