Alcatel Omniaccess Wlan Switch Direct-Connect Mode - Alcatel OmniAccess Wireless System 2.1 Product Manual

provides a 100/1000 Mbps wired connection to a network through an 850nM (SX) fiber-optic
link using an LC physical connector.
•
OAW-4024-DWP - 24-Port Alcatel OmniAccess WLAN Switch with built-in PoE Hub and an
optional 1000Base-T or 1000Base-SX/LC Network Adapter Module, used in
Mode, Appliance
provides a 100/1000 Mbps wired connection to a network through an 850nM (SX) fiber-optic
link using an LC physical connector.
•
(UNUSED COMPONENT) - 36-Port Alcatel OmniAccess WLAN Appliance with one 1000Base-SX/
LC Network Adapter, used only in
provides a 100/1000 Mbps wired connection to a network through an 850nM (SX) fiber-optic
link using an LC physical connector.
•
OAW-4102 - 36-Port Alcatel OmniAccess WLAN Appliance with one 1000Base-SX/LC Network
Adapter, used only in
redundant GigE connections to bypass single network failures. That is, at any given time one of
the 4102 Alcatel OmniAccess WLAN Appliance GigE connections is active and the other is
passive. Upon a network failure, the active connection becomes passive, and the passive
connection becomes active. Note that the 1000Base-SX Network Adapters provide 100/
1000 Mbps wired connections to a network through 850nM (SX) fiber-optic links using LC
physical connectors.
Note that all Alcatel OmniAccess Switch and Appliance models come from the factory with 19-inch EIA
equipment rack flush-mount ears and tabletop mounting feet.
The following upgrade modules are also available:
•
OAW-ESM - Enhanced Security Module: Supports VPN, L2TP, IPSec and other
processor-intensive security options. This is a factory-orderable and field-installable option for
all Alcatel OmniAccess Switches and Appliances.
•
OAW-GT - 1000Base-T Network Adapter Module: Supports 1000Base-T connections to the
network. This is a factory-orderable and field-installable option for 4012 and 4024 Alcatel
OmniAccess WLAN Switches.
•
OAW-GSX - Single-1000Base-SX Network Adapter Module: Supports 1000Base-SX connections
to the network. Note that the 1000Base-SX Network Adapter Module provides a 100/1000 Mbps
wired connection to a network through an 850nM (SX) fiber-optic link using an LC physical
connector. This is a factory-orderable and field-installable option for 4012 and 4024 Alcatel
OmniAccess WLAN Switches.
•
OAW-GSX2 - Dual-1000Base-SX Network Adapter Module: Supports two 1000Base-SX connec-
tions to the network. This is a factory-orderable and field-installable option for 4012 and 4024
Alcatel OmniAccess WLAN Switches. The dual-1000Base-SX module uses two redundant GigE
connections to bypass single network failures. At any given time one of the dual-1000Base-SX
module GigE connections is active and the other is passive. Upon a network failure, the active
connection becomes passive, and the passive connection becomes active. Note that the
1000Base-SX Network Adapter Module provides 100/1000 Mbps wired connections to a
network through 850nM (SX) fiber-optic links using LC physical connectors.

Alcatel OmniAccess WLAN Switch Direct-Connect Mode

The 4012 and 4024 Alcatel OmniAccess WLAN Switches can be operated in Direct-Connect Mode, in
Appliance Mode, or in
Layer 3 Operation). In Direct-Connect Mode, the Alcatel OmniAccess WLAN Switches are directly
connected to up to 24 (Model 4024) or up to 12 (Model 4012) OmniAccess AP Access Points and/or
Third-Party APs over CAT-5 or higher Ethernet cabling. The benefit of this mode is that the Alcatel
OmniAccess WLAN Switches can provide
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 30
Mode, and Hybrid Mode. Note that the 1000Base-SX Network Adapter Module
Appliance
Appliance Mode. The 4102 Alcatel OmniAccess WLAN Appliance uses two
Hybrid Mode, either in ISO Data Link Layer 2 or Network Layer 3
Power Over
Mode. Note that the 1000Base-SX Network Adapter
Direct-Connect Mode
Ethernet.
Direct-Connect Mode
Direct-Connect
(Layer 2 and
