Alcatel OmniAccess Wireless System 2.1 Product Manual page 281

11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 20
Mirroring Mode................................... Disabled
AP Mode.......................................... Local
Remote AP Debug.................................. Disabled
S/W Version..................................... 2.0.133.0
Boot Version.................................... 0.0.0.0
Stats Reporting Period........................... 180
Number Of Slots.................................. 2
Rad Model........................................
Rad Serial Number................................
Attributes for Slot
Radio Type................................... RADIO_TYPE_80211b
Administrative State......................... ADMIN_ENABLED
Operation State.............................. DOWN
WLAN Override................................ Disabled
CellId....................................... 0
Station Configuration
Configuration.............................. AUTOMATIC
Number Of WLANs............................ 0
Medium Occupancy Limit..................... 100
CFP Period................................. 4
CFP MaxDuration............................ 60
BSSID...................................... 00:0b:85:01:05:00
Operation Rate Set
1000 Kilo Bits........................... MANDATORY
2000 Kilo Bits........................... MANDATORY
5500 Kilo Bits........................... MANDATORY
11000 Kilo Bits.......................... MANDATORY
Beacon Period.............................. 100
DTIM Period................................ 1
Multi Domain Capability Implemented........ TRUE
Multi Domain Capability Enabled............ TRUE
Country String............................. US
Multi Domain Capability
Configuration.............................. AUTOMATIC
First Chan Num............................. 1
Number Of Channels......................... 11
Maximum Tx Power Level..................... 30
MAC Operation Parameters
Configuration.............................. AUTOMATIC
RTS Threshold.............................. 2347
Short Retry Limit.......................... 7
Long Retry Limit........................... 4
Fragmentation Threshold.................... 2346
Maximum Tx MSDU Life Time.................. 512
Maximum Rx Life Time....................... 512
Tx Power
Num Of Supported Power Levels.............. 5
Tx Power Level 1........................... 32
Tx Power Level 2........................... 16
Tx Power Level 3........................... 8
Tx Power Level 4........................... 4
Tx Power Level 5........................... 1
Tx Power Level 6........................... 0
Tx Power Level 7........................... 0
Tx Power Level 8........................... 0
Tx Power Configuration..................... AUTOMATIC
Current Tx Power Level..................... 1
1
show ap config
