Configure Calibration Model > Create New; Monitor Calibration Model > <Model> > Start Calibrating - Alcatel OmniAccess Wireless System 2.1 Product Manual

General
•
User Name: Name of the template.
•
Password and Confirm Password: Enter for this Local Management User template.
•
Access Level: Read Write or Read Only.
Command Buttons
•
Save
•
Cancel
Configure Calibration Model > Create New
Use Monitor/Maps, select RF Calibration Models, select the Create New Model command and click
GO to access this page.
This page allows you to add a new RF Calibration Model Name.
•
Enter the Model Name and click OK.
Command Buttons
•
OK: Save the new Calibration Model name and return to
•
Cancel
Monitor Calibration Model > <model> > Start Calibrating
Use Monitor/Maps, select RF Calibration Models, click a Not Yet Calibrated Model Name, select Add
Data Points and click GO to access this page.
This page assumes that OmniAccess AP Access Points have already been deployed on the floor area to
be used for calibration, and that the OmniAccess AP 1200 or 1250 icons have been placed on the ACS
floor area map.
This page allows you to enter the MAC address of a portable, wireless PC running ACS (used to collect
calibration data), and to select an existing floor area to be calibrated. These entries and selections must
be made before calibrating the RF Calibration Model.
Enter the following:
•
Enter MAC Address of Client: MAC address of a portable, wireless PC running ACS, used to
collect calibration data.
•
Campus: Any existing campus name, or Root Area, which contains the standalone buildings
(those buildings that are not part of a campus).
•
Building: Any existing building name. When you select a building name, ACS allows you to
select from a list of all available building floor names.
•
Floor Area: Any existing floor area name to be used for calibration.
Command Buttons
•
Next: Save the new Calibration Model parameters and continue with
Models.
•
Cancel
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 164
Configure Calibration Model > Create New
Configure Calibration Model > Create New
Monitor RF Calibration
Monitor Calibration Model > <model> > Start Calibrating
Monitor RF Calibration
Models.
