Alcatel OmniAccess Wireless System 2.1 Product Manual page 520

Table -
Station Configuration Parameters (Continued)
Parameters
Medium Occupancy
Limit
CFP Period
CFP Max Duration
BSSID
Beacon Period
DTIM Period
Country String
Table -
Operation Rate Set for 802.11b/g OmniAccess Radios
Parameter
1000 Kilo Bits
2000 Kilo Bits
5500 Kilo Bits
11000 Kilo Bits
The data rates set here are negotiated between the client and the Alcatel OmniAccess Switch
Note:
or Appliance. If the data rate is set to Mandatory, the client must support it in order to use the
network.
If a data rate is set as Supported by the Alcatel OmniAccess Switch or Appliance, any associated
client that also supports that same rate may communicate with the OmniAccess AP 1200 or 1250
using that rate. But it is not required that a client be able to use all the rates marked Supported in
order to associate. Each data rate can also be set to Disabled to match Client settings.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 71
Indicates the maximum amount of time, in TU, that a point coordinator
may control the usage of the wireless medium without relinquishing
control for long enough to allow at least one instance of DCF access to
the medium. The default value is 100, and the maximum value is 1000.
The number of DTIM intervals between the start of CFPs. It is modified by
MLME-START.request primitive.
The maximum duration of the CFP in TU that may be generated by the
PCF. It is modified by MLME-START.request primitive.
MAC address of the OmniAccess AP 1200 or 1250.
The rate at which the SSID is broadcast by the OmniAccess AP 1200 or
1250, from 100 to 600 milliseconds. Note that the Standalone WPS
Alcatel OmniAccess Wireless System described in About the Alcatel
OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product
Guide does not support beacon periods.
The number of beacon intervals that shall elapse between transmission of
Beacon frames containing a TIM element whose DTIM Count field is 0.
This value is transmitted in the DTIM Period field of Beacon frames. Note
that the Standalone WPS Alcatel OmniAccess Wireless System described
in About the Alcatel OmniAccess Wireless System in the Alcatel Omni-
Access Wireless Product Guide does not support WLANs or DTIM
parameters.
Identifies the country in which the station is operating. The first two
octets of this string is the two character country code as described in
Alcatel OmniAccess Wireless System Supported Regulatory Domains in
the Alcatel OmniAccess Wireless Product Guide.
Band
802.11b or 802.11g.
802.11b or 802.11g.
802.11b or 802.11g.
802.11b or 802.11g.
802.11b/g AP Interfaces > Details
Description
Range (Note)
Mandatory, Supported or Disabled.
Mandatory, Supported or Disabled.
Mandatory, Supported or Disabled.
Mandatory, Supported or Disabled.
