Using the Configuration Wizard

When the Alcatel OmniAccess Switch or Appliance is activated for the first time from the factory, or
when it has been rebooted after a
Interface displays the Web Configuration Wizard. Use the Configuration Wizard to configure the Alcatel
OmniAccess Switch or Appliance for initial operation.
Perform the following steps to enter the initial Alcatel OmniAccess Switch or Appliance configuration:
•

Collect the Initial Configuration Settings

•
Connect Your Web Browser to an Alcatel OmniAccess Switch or Appliance
•
Configuration Wizard System Information
•
Service Interface Configuration
•
Management Interface Configuration
•
Miscellaneous Configuration
•
Virtual Interface Configuration
•
WLAN Policy Configuration
•
RADIUS Server Configuration
•
802.11 Configuration
•
Configuration Wizard Completed
Collect the Initial Configuration Settings
Collect the high-level Alcatel OmniAccess WLAN Switch or Appliance parameters:
System Parameters
-
Alcatel OmniAccess Switch or Appliance name.
-
Supported protocols: 802.11a and/or 802.11b/g.
-
New usernames and passwords (optional).
Network (Distribution System) Parameters
-
Distribution System (network) port static IP Address, netmask, and optional default
gateway IP Address from the network planner.
-
Service port static IP Address and netmask from the network planner (optional).
-
Distribution System physical port (1000Base-T, 1000Base-SX, or 10/100Base-T). Note
that the 1000Base-SX Network Adapter Module provides a 100/1000 Mbps wired
connection to a network through an 850nM (SX) fiber-optic link using an LC physical
connector.
-
Distribution System port VLAN assignment (optional).
-
Distribution System port Web and Secure Web mode settings, enabled or disabled.
-
Distribution System port Spanning Tree Protocol: enabled/disabled, 802.1D/fast/off
mode per port, path cost per port, priority per port, bridge priority, forward delay, hello
time, maximum age.
WLAN Parameters
-
WLAN Configuration: VLAN assignments, Layer 2 Security settings, Layer 3 Security
settings, QoS assignments.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 125
Using the Configuration Wizard
Reset to Factory Default, the Alcatel OmniAccess Switch Web
Collect the Initial Configuration Settings
Using the Configuration Wizard
