Alcatel OmniAccess Wireless System 2.1 Product Manual page 623

Table -
General
Parameter
IP Address
Name
UP Time
System Time
Location
Total Client Count
Current LWAPP
Transport Mode
Table -
Inventory
Parameter
Software Version
Description
Model No.
Serial No.
Burned-in MAC Address
GigE Card Present
Crypto Card Present
•
GIGE Port(s) Status: Up or Down. Click to review the status of the port. Refer to
Switches > <IPaddr> > Ports >
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 44
Local network IP Address of the Alcatel OmniAccess Switch or Appliance
Management Interface, described in the Alcatel OmniAccess Wireless
Product Guide.
User-defined name of the Alcatel OmniAccess Switch or Appliance.
Time in days, hours and minutes since the last reboot.
Time used by the Alcatel OmniAccess Switch or Appliance.
User-defined physical location of the Alcatel OmniAccess Switch or
Appliance.
Total number of clients currently associated with the Alcatel OmniAccess
Switch or Appliance. Note that the Standalone WPS Alcatel OmniAccess
Wireless System described in About the Alcatel OmniAccess Wireless
System in the Alcatel OmniAccess Wireless Product Guide does not
support voice or data clients.
Lightweight Access Point Protocol transport mode. Communications
between Alcatel OmniAccess Switches or Appliances and access points.
Selections are Layer 2 or Layer 3.
The Alcatel OmniAccess Operating System release.version.dot.mainte-
nance number of the code currently running on the Alcatel OmniAccess
Switch or Appliance.
Description of the inventory item, for example, OmniAccess Wireless
Switch.
Specifies the Machine Model as defined by the Vital Product Data.
Unique Serial Number for this Alcatel OmniAccess Switch or Appliance.
The burned-in Medium Access Control address for this Alcatel OmniAccess
Switch or Appliance.
Displays the presence or absence of the optional 1000Base-T/
1000Base-SX GigE card.
Displays the presence or absence of an optional Enhanced Security Module
which enables IPSec security and which provides enhanced processing
power.
n.
Monitor Switches > <IPaddr> > Summary
Description
Description
Monitor
