Alcatel OmniAccess Wireless System 2.1 Product Manual page 488

Table -
Inventory Parameters
Parameter
System Description
Model No.
Serial Number
Burned-in MAC Address
Gig Ethernet/Fiber Card
Crypto Accelerator
Command Buttons
•
Help: Request that the help page be displayed in a new browser window.
Interfaces
Interfaces
Use SWITCH/Interfaces to navigate to this page.
The following table shows Alcatel OmniAccess Switch or Appliance interface general parameters.
To edit the parameters for an interface, select the Edit link
Remove an interface by selecting the appropriate Remove link. You are prompted for confirmation of
the interface removal.
Table -
Alcatel OmniAccess Switch or Appliance Interface Parameters
Parameter
Interface Name
VLAN Identifier
IP Address
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 39
Product name of this Alcatel OmniAccess Switch or Appliance.
Specifies the model as defined by the factory.
Unique Serial Number for this Alcatel OmniAccess Switch or
Appliance.
The burned-in Medium Access Control address for this Alcatel
OmniAccess Switch or Appliance.
Displays the presence or absence of the optional 1000Base-T/
1000Base-SX GigE card.
Displays the presence or absence of an optional Enhanced
Security Module (Crypto card) which enables IPSec security and
which provides enhanced processing power.
Name of the interface:
• management -- 802.11 Distribution System wired network.
• service-port -- System Service interface.
• virtual -- Unused IP address used as the Virtual Gateway
Address.
• ap-manager -- Only used when the LWAPP protocol is run
across Layer 3. Can be on the same subnet as the manage-
ment IP address, but must have a different IP address than the
management interface.
• <name> -- An Operator-Defined Interface assignment, without
any spaces.
Virtual LAN assignment of the interface.
The IP address of the Alcatel OmniAccess Switch or Appliance
and its distribution port.
Description
(Interfaces > Edit).
Description
Interfaces
