This page allows you to edit a specific floor on a map:
Floor Name: The user-defined name of the floor.
Contact: The name of the person responsible for the design of this floor.
Floor: The number of the floor.
Floor Height (feet): The ceiling height of the selected floor.
Image File: Displays the path of the floor graphic, or two graphics, if a .FPE file was imported
for this floor. To change the image, use the Browse button.
Maintain Aspect Ratio: Select this checkbox to maintain the aspect ratio (ratio of horizontal and
vertical pixels) of the map image. Maintaining the aspect ratio prevents visual distortion of the
map.
Dimension (feet): Enter the Horizontal Span (the distance from left to right on the map display)
and the Vertical Span (the distance up and down on the map display) and click Place to make
the changes take place on the grid.
Position (feet): Using the mouse, move the blue rectangle to the desired location.
Note:
and select the command Properties from the pulldown.
Resizing non-FPE graphics: Hold down the <CTRL> key, left-click and drag the corner of the
image. Note that this does not work for FPE images, as the size of the image is defined in the
FPE file.
Command Buttons
Place: Fixes the changes on the display.
Save: Saves the changes in the database.
Cancel: Cancels the operation.

CONFIGURE/SWITCHES MENU BAR SELECTION

This menu bar selection provides access to the Alcatel OmniAccess Switch or Appliance summary
details. Use the selector area to access and configure the respective Alcatel OmniAccess Switch or
Appliance details. Making this selection displays

Configure All Switches

Use CONFIGURE/Switches to access this page.
This page allows you to view a summary of all Alcatel OmniAccess Switches and Appliances in the ACS
Software database. It also allows you to add Alcatel OmniAccess Switches and Appliances, remove and
reboot selected Alcatel OmniAccess Switches and Appliances, download software from the ACS Server
to selected Alcatel OmniAccess Switches and Appliances, save the current configuration to nonvolatile
(Flash) memory on selected Alcatel OmniAccess Switches and Appliances, and view audit reports for
selected Alcatel OmniAccess Switches and Appliances.
The data area of this page contains a table with the following columns:
Checkbox: Click to select the Alcatel OmniAccess Switch or Appliance.
IP Address: Local network IP Address of the Alcatel OmniAccess Switch or Appliance
Management Interface, described in the Alcatel OmniAccess Wireless Product Guide. Click the
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 112
To change the unit of measurement (feet or meters), select Monitor > Maps
Configure All Switches
CONFIGURE/SWITCHES MENU BAR SELECTION
CONFIGURE/SWITCHES MENU BAR SELECTION
Configure All
Switches.
