Alcatel OmniAccess Wireless System 2.1 Product Manual page 750

Table -
Layer 2 Security Policies (Continued)
Parameter
One unique WEP Key Index can be applied to each WLAN. As there are only four WEP Key
Note 1:
Indexes, only four WLANs can be configured for Static WEP Layer 2 encryption.
When Cranite is selected as the Layer 2 security policy, no Layer 3 security policies are
Note 2:
allowed.
The Third-Party AP WLAN (17) can only be configured with 802.1X encryption as described in
Note 3:
Third-Party Access Points in the Alcatel OmniAccess Wireless Product Guide. Drop down configurable
802.1X parameters are not available for this WLAN.
Table -
802.1X Parameters
Parameter
802.11 Data Encryption
Radio Button
Type
Key Size
Key Index
Encryption Key
Key Format
The values in these fields and the fields themselves change depending upon the security
Note:
policies selected.
Layer 3 security is available via VPN Pass Through or IPSec. Check software availability and client
hardware compatibility before implementing IPSec. Layer 3 IPSec parameters are described in the
following table.
Table -
WPA Parameters
Parameter
802.11 Data Encryption
Type
Key Size
Preshared Key Mode
VPN Pass through: Available only when VPN Pass through is selected for Layer 3 Security. Displays
the IP Address of the VPN Gateway Address.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 171
Displays the current Key of the security selected in the Security Policies
area.
Active when there is more than one type of encryption available.
WEP, TKIP-MIC.
40 bits, 104 bits, 128 bits.
1 through 4. One unique WEP Key Index can be applied to each WLAN.
As there are only four WEP Key Indexes, only four WLANs can be
configured for Static WEP Layer 2 encryption.
Encryption Key.
ASCII or HEX.
Displays the current Key of the security selected in the Security Policies
area.
Active when there is more than one type of encryption available.
TKIP-MIC.
Enable checkbox.
Configure WLAN Template > Template <name>
Description
Description
Description
