Access Control Lists > Rules > Edit - Alcatel OmniAccess Wireless System 2.1 Product Manual

Table -
New Rule Parameters (Continued)
Parameter
Protocol (Note 1)
DSCP
Direction
Action (Note 2)
When you select some of these protocols, one or more additional data entry fields open up.
Note 1:
Enter the port number in a single data entry field, or enter the source and destination port when
there are two data entry fields.
The default filter is to deny all access unless a Rule explicitly permits it.
Note 2:
•
Use Add New Rule to add the new rule to the Access Control List.
Command Buttons
•
Back: Return to the previous window.
•
Help: Request that the help page be displayed in a new browser window.
Access Control Lists > Rules > Edit
Use SECURITY/Access Control Lists then Edit and then Edit again to navigate to this page.
Note that the Standalone WPS Alcatel OmniAccess Wireless System described in About the Alcatel
OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not support ACLs.
This page allows you to change an Access Control List Rule definition. Note that the Alcatel OmniAccess
Operating System allows you to define up to 64 ACLs, with up to 64 Rules (filters) per ACL.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 97
Protocol to use for this ACL:
• Any - All protocols
• TCP - Transmission Control Protocol
• UDP - User Datagram Protocol
• ICMP - Internet Control Message Protocol
• ESP - IP Encapsulating Security Payload
• AH - Authentication Header
• GRE - Generic Routing Encapsulation
• IP - Internet Protocol
• Eth Over IP - Ethernet over Internet Protocol
• OSPF - Open Shortest Path First
• Other - Any other IANA protocol (http://www.iana.org/)
Any or Specific (from 0 - 63). Differentiated Services Code Point
(DSCP). A packet header code that can be used to define quality
of service across the Internet.
Any, Inbound (from client) or Outbound (to client).
Deny or Permit.
Access Control Lists > Rules > Edit
Access Control Lists > Rules > Edit
Description
