Configure Local Net Users

Use CONFIGURE/Switches, click an IP address under the IP Address column, on the left sidebar
menu, select Security and click Local Net Users to access this page.
This page allows you to view existing local network users.
•
Checkbox: Use to select Local Net User names to delete.
•
User Name: User-defined identification. Click any name to have ACS display
Net Users > Template
•
WLAN ID: Any WLAN ID, 1 through 17, or 0 for all WLANs.
•
Description: Optional user-defined description.
Select a command
•
Add Local Net User: Select and click GO to have ACS display
Template.
•
Delete Local Net Users: Select Local Net User names using the checkbox(es), select this
command and click GO to have ACS prompt you for Local Net User name deletion.

Configure Local Net Users Switch

Use CONFIGURE/Switch and from the left sidebar menu, select Security/Local Net Users to access
this page.
This page presents a summary of the existing local network user templates for clients who are allowed
to access a specific Alcatel WLAN. This is an administrative bypass of the RADIUS authentication
process. Layer 3 Web Authentication must be enabled. The client information is passed to the RADIUS
authentication server first, and if the client information does not match a RADIUS database entry, this
local database is polled. Clients located in this database are granted access to network services if the
RADIUS authentication fails or does not exist.
This page displays a table with the following columns:
•
Checklist: Checkmark for deletion.
•
User Name: Click a list item. Refer to
and apply the template.
•
WLAN ID: WLAN ID 1 through 16, or 17 = Third-Party WLAN that this local net user is allowed
to access.
•
Description: Optional user-defined description.
Select a command
Select a command
•
Add Template: Refer to
•
Delete Local Net Users: Checkmark one or more of the local net user entries, select this
command, and click GO.
Monitor Switches > <IPaddr> > Mobility Stats
Use MONITOR/Switches and click one of the IP addresses under IP Address, then from the Sidebar
menu, under Mobility select Mobility Stats to access this page.
Use MONITOR/Access Points, click a list item under AP Name, click Registered Switch, then from
the Sidebar menu, under Mobility select Mobility Stats to access this page.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 57
Configure Local Net Users
<name>.
Configure Local Net Users Switch
Configure Local Net Users > Template <name>
Configure <IPaddr> > Local Net Users > Add From
Configure Local Net Users > New
Monitor Switches > <IPaddr> > Mobility Stats
Configure Local Net Users
Configure Local
to view
Template.
