This page allows you to add a template of OmniAccess Radio information that you can apply to one or
more OmniAccess Radios.
Table -
OmniAccess Radio Parameters
Column
Checkboxes
RF Channel Assignment
Custom Channel
Tx Power Level
Assignment
Custom Channel
Admin Status
Antenna Type
Antenna Mode
Antenna Diversity
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 145
Checkmark to select the parameter to apply to one or more OmniAccess
Radios.
Channels may be set either Globally by the Alcatel OmniAccess Switch or
Appliance or locally using the Custom option.
The assignment method should normally be left at the Global
Note:
setting. This allows the Alcatel OmniAccess Switch or Appliance to dynam-
ically change the channel number as determined by the OmniVista AirView
Software.
(Only if Custom RF Channel Assignment is selected.) Channel number of
the OmniAccess Radio.
Transmit power may be set either Globally by the Alcatel OmniAccess
Switch or Appliance or locally using the Custom option.
The assignment method should be left at the Global setting. This
Note:
allows the Alcatel OmniAccess Switch or Appliance to dynamically change
the transmit power level based on the OmniVista AirView Software.
(Only if Custom Tx Power Level Assignment is selected.) Transmit Power
Level of the OmniAccess Radio.
OmniAccess Radio transmit power level (1 = Maximum power allowed per
Country Code setting, 2 = 50% power, 3 = 25% power, 4 = 12.5%
power, and 5 = 6.25% power).
Note that the power levels and available channels are defined by the
Country Code setting, and are regulated on a country by country basis.
Refer to Supported Regulatory Domains in the Alcatel OmniAccess
Wireless Product Guide for the maximum Transmit Power Levels for each
country.
Optionally enter the OmniAccess Radio administrative status: Check-
marked = Enabled, Blank = Disabled.
Internal or External. (802.11b/g radios only.)
Sector A, Sector B, or OMNI ( = Sector A and Sector B). (802.11a radios
only.)
(802.11b/g radios only.)
For internal antennas: Enable diversity, or select Side A for the front
(door) antenna, or select Side B for the rear antenna.
For External antennas, Enable diversity, or select Right for the Right
(Connector B) antenna, or select Left for the Left (Connector A) antenna.
Options
Configure Radio Template
