Table -
Alcatel OmniAccess Switch or Appliance Layer 3 Access Point Management Interface Parameters
Parameter
VLAN Identifier
IP Address
Netmask
Gateway
Port Number
Primary DHCP Server
Secondary DHCP Server
ACL Name
You may only create a Layer 3 LWAPP Access Point manager after the Alcatel OmniAccess
Note:
Switch or Appliance has been rebooted to use Layer 3 LWAPP protocol.
Command Buttons
•
Back: Return to the previous window.
•
Apply: Data is sent to the Alcatel OmniAccess Switch or Appliance and made to take effect, but
not preserved across a power cycle; these parameters are stored temporarily in volatile RAM.
Applying Interface changes may cause WLANs to temporarily drop client connections. You will
be prompted to confirm the changes if this is the case.
•
Help: Request that the help page be displayed in a new browser window.

Network Routes

Network Routes
Use SWITCH/Network Routes to navigate to this page.
This page provides a summary of existing Service port Network Routes to Network or Element Manage-
ment systems on a different subnet by IP Address, IP Netmask, and Gateway IP Address.
Remove a Network Route by selecting the appropriate Remove link. You are prompted for confirmation
of the Network Route removal.
Command Buttons
•
New: Select to add a new Network Route.
•
Help: Request that the help page be displayed in a new browser window.
Network Routes > New
Use SWITCH/Network Routes then New... to navigate to this page.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 42
Virtual LAN assigned to the interface.
The IP address of the Alcatel OmniAccess Switch or Appliance
Layer 3 LWAPP protocol manager. Note that this IP address
cannot be the same as used by the Management Interface.
Interface subnet mask.
Interface gateway router IP address.
The Alcatel OmniAccess Switch or Appliance physical port for this
interface.
The interface uses this DHCP server first to obtain an IP address.
The interface uses this DHCP server as a backup to obtain an
IP address.
Any of the Access Control List Names currently available on the
Access Control Lists
Network Routes > New
Description
page.
Network Routes
