Table -
Summary Parameters
Parameter
Port No Port number on the Alcatel OmniAccess
Switch or Appliance.
STP Status State of the Spanning Tree Protocol
Administrative Mode associated with the
port.
Admin Mode Displays the state of the port.
Physical Mode Displays the configuration of the port
physical interface.
Physical Status Displays the actual port physical interface.
Link Status Displays the status of the link.
Link Trap Displays if the port is set to send a trap
when link status changes.
POE Displays status of Power over Ethernet
functionality.
Mcast Sets support for multicast appliance
Appliance mode.
The physical mode and status may reflect different values depending on the link status. For example,
the physical mode may be set to "Auto" while the actual link is running at "10 Mbps Half Duplex".
To edit global parameters across all ports, click the ConfigureAll command button to open the
Configure page.
To edit the parameters for a single port, select the Edit link for the port you wish to configure. This
brings up a Port > Configure
Command Buttons
•
ConfigureAll: Open the Global Port configuration data page.
•
Help: Request that the help page be displayed in a new browser window.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 49
Description
page.
Range
• 1 to 12 for 4012, and 13 for
optional 1000Base-T or
1000Base-SX module
• 1 to 24 for 4024, and 25 for
optional 1000Base-T or
1000Base-SX module
• 1 for 4102 1000Base-SX ports
• Enabled
• Disabled
• Forwarding
• Enable
• Disable
• Auto
• 100 Mbps Full Duplex
• 100 Mbps Half Duplex
• 10 Mbps Full Duplex
• 10 Mbps Half Duplex
• Auto
• 100 Mbps Full Duplex
• 100 Mbps Half Duplex
• 10 Mbps Full Duplex
• 10 Mbps Half Duplex
• Link Up
• Link Down
• Enable
• Disable
• Enable
• Disable
• Enable
• Disable
Ports
Ports >
