Alcatel OmniAccess Wireless System 2.1 Product Manual page 518

Table -
Antenna (Continued)
Parameter
Diversity
Table -
WLAN Override
Parameter
WLAN Override
When you enable WLAN Override, the Alcatel OmniAccess Operating System displays a table
Note:
showing all current Alcatel WLANs. In the table, select WLANs to enable WLAN operation, and
deselect WLANs to disallow WLAN operation for this 802.11b/g OmniAccess Radio.
Also note that the Standalone WPS Alcatel OmniAccess Wireless System described in About the
Alcatel OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not
support WLANs.
Table -
RF Channel Assignment
Parameter
Current Channel
Assignment Method
The assignment method should normally be left at the global setting. This allows the Alcatel
Note:
OmniAccess Switch or Appliance to dynamically change the channel number based OmniVista AirView
Software directives.
Table -
Tx Power Level Assignment
Parameter
Current Tx Power Level
Assignment Method
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 69
For internal antennas, Enable diversity, or select Side A for the front
(door) antenna, or select Side B for the rear antenna.
For External antennas, Enable diversity, or select Right for the Right
(Connector B) antenna, or select Left for the Left (Connector A) antenna.
Enable or disable WLAN Override for this 802.11b/g OmniAccess Radio.
Channel number of the OmniAccess AP 1200 or 1250. Note that only
channels 1, 6, and 11 are non-overlapping.
Channels may be set either Globally by the Alcatel OmniAccess Switch or
Appliance or locally using the Custom option.
OmniAccess AP 1200 or 1250 transmit power level (1 = Maximum power
allowed per Country Code setting, 2 = 50% power, 3 = 25% power,
4 = 12.5% power, and 5 = 6.25% power).
Note that the power levels and available channels are defined by the
Country Code setting, and are regulated on a country by country basis.
Refer to Alcatel OmniAccess Wireless System Supported Regulatory
Domains in the Alcatel OmniAccess Wireless Product Guide for the
maximum Transmit Power Levels for each country.
Transmit power may be set either globally by the Alcatel OmniAccess
Switch or Appliance or locally using the custom option.
802.11b/g OmniAccess Radios > Configure
Description
Description
Description
Description
