To size the blue rectangle, press the <CTRL> key and drag the corner of the rectangle to the
desired size.
Sidebar: Maps
•
Search for All Maps, Campuses, Buildings, Floor Areas, Outdoor Areas, Access Points.
•
Enter Name:
•
Search Button
Configure Maps > Edit Building > <name>
Use MONITOR/Maps, click a Building item in the Name column, from the Select a command
pulldown, select Edit Building to access this page.
This page allows you to edit a selected building:
•
Building Name: User-defined name of the building.
•
Contact: User-defined contact name.
•
Number of Floors: Enter the desired number of floors in the building.
•
Number of Basements: Enter the desired number of basements in the building.
•
Dimensions (feet/meters):
-
Width: Horizontal measurement (left to right) of the floor as it appears on the page.
-
Length: Vertical measurement (up and down) of the floor as it appears on the page.
Command Buttons
•
OK
•
Cancel
Configure Access Points > Access Point > <name>
Use CONFIGURE/Access Points and select a list item under AP Name to access this page.
This page contains configuration information about specific APs:
Table -
General
Parameter
Name
MAC Address
IP Address
Admin Status
AP Mode
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 193
Configure Maps > Edit Building > <name>
Set the customer definable name of the OmniAccess AP 1200 or
1250.
Media Access Control address of the OmniAccess AP 1200 or 1250.
OmniAccess AP 1200 or 1250, or 0.0.0.0 if unknown.
Check the box to indicate the administration state of the OmniAccess
AP 1200 or 1250 as enabled.
Status of the OmniAccess AP 1200 or 1250 Monitor mode (Monitor,
Local, or Remote).
Configure Maps > Edit Building > <name>
Configure Access Points > Access Point > <name>
Description
