Alcatel OmniAccess Wireless System 2.1 Product Manual page 657

Table -
General (Continued)
Parameter
Operational Status
Channel
Power Level
Switch
Port
Map Location
Table -
Station Configuration Parameters
Parameter
Configuration Type
Number of WLANs
Medium Occupancy Limit
CFP Period
CFP Max. Duration
BSSID
Beacon Period
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 78
Displays the operational status of the OmniAccess Radios (Up or
Down).
The channel the OmniAccess Radio is broadcasting on.
OmniAccess AP 1200 or 1250 transmit power level (1 = Maximum
power allowed per Country Code setting, 2 = 50% power, 3 = 25%
power, 4 = 12.5% power, and 5 = 6.25% power). Refer to
Supported Regulatory Domains in the Alcatel OmniAccess Wireless
Product Guide for the maximum Transmit Power Levels for each
country.
IP Address of Alcatel OmniAccess Switch or Appliance. Click to
display Monitor Switches > <IPaddr> >
Port to which the OmniAccess AP 1200 or 1250 is connected.
Refer to Monitor Maps > <campus> > <building> > <floor
Automatic or Custom.
1 (one) is the default. Note that the Standalone WPS Alcatel Omni-
Access Wireless System described in About the Alcatel OmniAccess
Wireless System in the Alcatel OmniAccess Wireless Product Guide
does not support WLANs.
Indicates the maximum amount of time, in TU, that a point coordi-
nator may control the usage of the wireless medium without
relinquishing control for long enough to allow at least one instance of
DCF access to the medium. The default value is 100, and the
maximum value is 1000.
The number of DTIM intervals between the start of CFPs.
The maximum duration of the CFP in TU that may be generated by
the PCF.
MAC address of the OmniAccess AP 1200 or 1250.
The rate at which the SSID is broadcast by the OmniAccess AP 1200
or 1250, from 100 to 600 milliseconds. Note that the
Standalone WPS Alcatel OmniAccess Wireless System described in
About the Alcatel OmniAccess Wireless System in the Alcatel Omni-
Access Wireless Product Guide does not support beacon periods.
Monitor Access Points > <name> > <radio type>
Description
Summary.
Description
area>.
