Alcatel OmniAccess Wireless System 2.1 Product Manual page 475

Table -
Quality of Service Properties
Parameter
QoS Level
Diff Serv Code Point
802.1P Tag
Table -
Client Statistics
Parameter
Bytes Received
Bytes Sent
Packets Received
Packets Sent
Policy Errors
RSSI
SNR
The Client Properties table identifies the properties of the client's access point and of the client's nego-
tiated session.
Table -
Client Properties
Parameter
AP Address
AP Name
AP Type
WLAN SSID
Status
Association ID
802.11 Authentication
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 26
Quality of Service Level. Gold (Highest); Silver (Mid-range); Bronze
(Low). Services such as VoIP should be set to Gold while non-discrimi-
nating services such as text messaging can be set to Bronze.
Differentiated Services Code Point received from client: Any, or 0
through 63.
Total number of bytes received by the Alcatel OmniAccess Switch or
Appliance from the client.
Total number of bytes sent to the client from the Alcatel OmniAccess
Switch or Appliance.
Total number of packets received by the Alcatel OmniAccess Switch or
Appliance from the client.
Total number of packets sent to the client from the Alcatel OmniAccess
Switch or Appliance.
Number of policy errors for the client.
Receive signal strength indicator of the client RF session.
Signal to noise ratio of the client RF session.
MAC address of the access point.
Name of the access point.
Access point's RF type.
Name of the WLAN.
Status of client from status code (see Status Code below).
Client's AP association identification number.
Authentication algorithm of client.
Description
Description
Description
Clients > Detail
