Configure <Ipaddr> > Radius Parameters; Configure Local Net Users > New Template - Alcatel OmniAccess Wireless System 2.1 Product Manual

Table -
General (Continued)
Parameter
Server Address
No. of Switches Applied
To
Port Number
Shared Secret, Confirm
Shared Secret
Admin Status
Configure <IPaddr> > RADIUS Parameters
Use CONFIGURE/Switches and click an IP address under the IP Address column, then on the left
sidebar menu, select Security/RADIUS Auth Servers, then select Edit RADIUS Parameters and click
GO to access this page.
This page allows you to edit existing RADIUS parameters
•
Cache credentials locally (For use with one time passwords only): Select Disable or Enable.
•
Call Station ID Type: IP Address, System MAC Address, or AP MAC Address.
Command Buttons
•
Save
•
Audit
•
Cancel
Configure Local Net Users > New Template
Use CONFIGURE/Templates, on the left sidebar menu select Security/Local Net Users, from the
Select a command pulldown select Add Template.
This page allows you to add a new local authentication template. Add the following information:
•
User Name: User-defined identification.
•
Password.
•
Confirm Password.
•
SSID (pulldown): Select an SSID name, or Any SSID.
•
Description: Optional user-defined description.
Command Buttons
•
Save: Save the Local Net User configuration and have ACS display
Template <name>.
•
Cancel
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 150
IP Address of the RADIUS server (read only).
Number of Alcatel OmniAccess Switches and Appliances to which this
template is applied (read only).
Alcatel OmniAccess Switch or Appliance port (read only).
The Shared Secret that acts as a password to the RADIUS accounting
server.
Enabled or disabled (read only).
Configure <IPaddr> > RADIUS Parameters
Description
Configure <IPaddr> > RADIUS Parameters
Configure Local Net Users > New Template
Configure Local Net Users >
