SNMP v1/v2c Community

Use MANAGEMENT/SNMP/Communities to navigate to this page.
This page provides a summary of the SNMP community as described in the following table.
Table -
SNMP Community Summary
Parameter
Community Name
IP Address
IP Mask
Access Mode
Status
Edit a user profile by selecting the Edit link
Remove a user profile by selecting the appropriate Remove link. You are prompted for conformation of
the user removal.
Command Buttons
•
New: Select to add a new community user profile
•
Help: Request that the help page be displayed in a new browser window.
SNMP v1/v2c Community > New
Use MANAGEMENT/SNMP Communities then New... to navigate to this page.
Use this page to add a new SNMP community profile as described in the following table.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 108
SNMP v1/v2c Community
The community string to which this entry grants access. A valid entry is a
case-sensitive alphanumeric string of up to 16 characters. Each row of
this table must contain a unique community name.
An IP address from which this device accepts SNMP packets with the
associated community. The requesting entity's IP address is ANDed with
the Subnet Mask before being compared to the IP Address.
If the Subnet Mask is set to 0.0.0.0, an IP Address of 0.0.0.0
Note:
matches all IP addresses. The default value is 0.0.0.0.
A mask to be ANDed with the requesting entity's IP address before
comparison with IP Address. If the result matches with IP Address then
the address is an authenticated IP address.
For example, if the IP Address = 9.47.128.0 and the corresponding
Subnet Mask = 255.255.255.0 a range of incoming IP addresses would
match, that is, the incoming IP Address could equal 9.47.128.0 -
9.47.128.255. The default value is 0.0.0.0.
The access level for this community string. May be specified by selecting
Read/Write or Read Only from the pulldown.
The status of this community access entry. When this object is set to
enabled, if the Community Name for this row is not unique among all
valid rows, the set request is rejected.
(SNMP v1/v2c Community >
SNMP v1/v2c Community > New
Range
Edit).
(SNMP v1/v2c Community >
SNMP v1/v2c Community
New).
