C.
From the <IP address> > Switch General page, select System/Commands to display
the <IP address> > Switch Commands page.
D.
On the <IP address> > Switch Commands page, under Administrative Commands,
select Save Config to Flash and click GO to save the changed configuration to the
Alcatel OmniAccess Switch or Appliance.
E.
On the <IP address> > Switch Commands page, under Administrative Commands,
select Reboot and click GO to reboot the Alcatel OmniAccess Switch or Appliance. Then
click OK to confirm the save and reboot.
9.
After the Alcatel OmniAccess Switch or Appliance has rebooted, verify that the LWAPP Trans-
port Mode is now Layer 3:
A.
Select CONFIGURE/Switches to navigate to the All Switches page, and select the
desired Alcatel OmniAccess Switch or Appliance by IP address to have ACS display the
<IP address> > Switch General page.
B.
From the <IP address> > Switch General page, select System/Networking to display
the <IP address> > Networking Setups page.
C.
On the <IP address> > Networking Setups page, verify that the Current LWAPP Trans-
port Mode is Layer 3.
10.
Select CONFIGURE/Access Points to navigate to the All Access Points page, and MAKE
SURE that the OmniAccess AP Access Points are associated with the Alcatel OmniAccess Switch
or Appliance before you continue with the next step. If you do not complete this step, the
OmniAccess AP Access Points may fail to associate with the desired Alcatel OmniAccess Switch
or Appliance after completing the conversion.
11.
Power down each OmniAccess AP 1200 or 1250 to save the Layer 3 configuration to nonvolatile
memory.
12.
Connect each OmniAccess AP 1200 or 1250 to its final location in the network. Each Omni-
Access AP 1200 or 1250 connects to its Primary Alcatel OmniAccess Switch or Appliance,
downloads a copy of the latest Alcatel OmniAccess Operating System code, and starts reporting
its status to the Alcatel OmniAccess Switch or Appliance. Note that this can take a few minutes
for each OmniAccess AP 1200 or 1250.
You have completed the LWAPP Transport Mode conversion from Layer 2 to Layer 3. The ap-manager
interface now controls all communications between Alcatel OmniAccess Switches or Appliances and
OmniAccess AP Access Points on different subnets. Continue with the
Product Guide.
