<vendor:MACaddr> page. From the Select a command pulldown, select Event History to access this
page.
This page allows you review information about rogue alarm events.
Click the title of each column to reorder the listings:
•
Severity: Color coded display of the severity of the event. Refer to
•
Rogue MAC Address: Click a list item to display information about the entry. Refer to
Alarm > Events > Rogue -
•
Vendor: Name of rogue AP manufacturer.
•
Type: AP or AD-HOC.
•
On Network: Whether or not the rogue AP is on the same subnet as the associated Alcatel
OmniAccess Switch or Appliance.
•
On 802.11a: Whether or not the rogue AP is broadcasting on the 802.11a band.
•
On 802.11b: Whether or not the rogue AP is broadcasting on the 802.11b/802.11g band.
•
Date/Time: Date and time of the alarm.
•
State: State of the alarm, such as Alert and Removed.
•
SSID: Service Set Identifier being broadcast by the rogue access point radio.
Left sidebar
•
Severity (pulldown): All Severities, Critical, Major, Minor, Warning, Clear, Info.
•
Alarm Category: All Types, AP, Switch, Security, Coverage, Rogue AP.
•
Rogue AP State (only shown when Rogue AP Alarm Category is selected): All States, Alert,
Known, Acknowledged, Contained, Threat, Contained Pending, Removed.
•
Search for Rogue APs by (only shown when Rogue AP Alarm Category is selected): All APs, AP
Name, Floor Area, Outdoor Area.
•
Enter AP Name (only shown when Rogue AP Alarm Category and Search for Rogue APs by AP
Name are selected): Enter the desired Rogue AP Name.
•
Select Radio Type (only shown when Floor Area Alarm Category, or Rogue AP Alarm Category
and Search for Rogue APs by AP Name are selected): All Radios, 802.11a, 802.11b/g.
•
Campus (only shown when Rogue AP Alarm Category and Search for Rogue APs by Floor Area/
Outdoor Area are selected): Root Area, <Campus Name>.
•
Outdoor Area (only shown when Rogue AP Alarm Category and Search for Rogue APs by
Outdoor Area are selected): Outdoor Area, <Outdoor Area Name>.
•
Building (only shown when Rogue AP Alarm Category and Search for Rogue APs by Floor Area
are is selected): All Buildings, <Building Name>.
•
Floor Area (only shown when Rogue AP Alarm Category and Search for Rogue APs by Floor Area
are selected): All Floors, <Floor Area Name>.
•
Access Point (only shown when Rogue AP Alarm Category and Search for Rogue APs by Floor
Area/Outdoor Area are selected): All Access Points, <Access Point Name>.
•
Search button.
