Monitor Alarms > Rogue AP <MACaddress> > Detecting APs
Click a Rogues alarm square in the Alarm Monitor (lower left-hand side of the screen) to access the
Monitor Rogue AP Alarms
Address to access the
pulldown, select Detecting APs to access this page.
Select MONITOR/Alarms, and then select Severity/All Severities and Alarm Category/Rogue AP
and click Search in the left sidebar to access
Alarms page, click an item under Rogue MAC Address to access
<vendor:MACaddr>. In the Monitor Alarms > Rogue - <vendor:MACaddr> page, from the Select a
command pulldown, select Detecting APs to access this page.
This page allows you to view information about the OmniAccess AP Access Points that are detecting a
rogue access point.
Click a list item to display data about that item:
•
AP Name: Refer to
•
Radio: Refer to
•
Map Location: Refer to
•
SSID: Service Set Identifier being broadcast by the rogue access point radio.
•
Channel Number: Which channel the rogue access point is broadcasting on.
•
WEP: Enabled or disabled.
•
WPA: Enabled or disabled.
•
Pre-Amble: Long or short.
•
RSSI: Received signal strength indicator in dBm.
•
SNR: Signal-to-noise ratio.
•
Containment Type: Type of containment applied from this OmniAccess AP 1200 or 1250.
•
Containment Channels: Channels that this OmniAccess AP 1200 or 1250 is currently containing.
Left sidebar
•
Severity (pulldown): All Severities, Critical, Major, Minor, Warning, Clear, Info.
•
Alarm Category: All Types, AP, Switch, Security, Coverage, Rogue AP.
•
Rogue AP State (only shown when Rogue AP Alarm Category is selected): All States, Alert,
Known, Acknowledged, Contained, Threat, Contained Pending, Removed.
•
Search for Rogue APs by (only shown when Rogue AP Alarm Category is selected): All APs, AP
Name, Floor Area, Outdoor Area.
•
Enter AP Name (only shown when Rogue AP Alarm Category and Search for Rogue APs by AP
Name are selected): Enter the desired Rogue AP Name.
•
Select Radio Type (only shown when Floor Area Alarm Category, or Rogue AP Alarm Category
and Search for Rogue APs by AP Name are selected): All Radios, 802.11a, 802.11b/g.
•
Campus (only shown when Rogue AP Alarm Category and Search for Rogue APs by Floor Area/
Outdoor Area are selected): Root Area, <Campus Name>.
•
Outdoor Area (only shown when Rogue AP Alarm Category and Search for Rogue APs by
Outdoor Area are selected): Outdoor Area, <Outdoor Area Name>.
11/5/04 Monitor Alarms > Rogue AP <MACaddress> > Detecting APs
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 21
page. In the Monitor Rogue AP Alarms page, click an item under Rogue MAC
Monitor Alarms > Rogue - <vendor:MACaddr>
Monitor Access Points >
Monitor Access Points > <name> > <radio
Monitor Maps > <campus> > <building> > <floor
Monitor Rogue AP Alarms. In the Monitor Rogue AP
Monitor Alarms > Rogue -
<name>.
type>.
Monitor Alarms > Rogue AP <MACaddress> > Detecting APs
page, from the Select a command
area>.
