Monitor Access Points > <Name - Alcatel OmniAccess Wireless System 2.1 Product Manual

Table -
Generate Report for Selected APs Pulldown (Continued)
Command
Coverage (SNR)
Up Time
Monitor Access Points > <name>
Use MONITOR/Access Points and click a list item under AP Name to access this page.
Use MONITOR/Clients and click a list item under AP Name to access this page.
Use MONITOR/Switches and click an item under IP Address, then click an item under Access Points
to access this page.
Note that the Standalone WPS Alcatel OmniAccess Wireless System described in About the Alcatel
OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not support this
page.
This page allows you to view access point information for a single AP.
Click Access Points in the page title to view a list of all APs. Refer to
Table -
General
Parameter
AP Name
AP MAC Address
AP IP Address
Admin Status
Monitor Only Mode
Operational Status
Registered Switch
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 73
Generates a report with Coverage (SNR) information. Refer to
Access Points > Coverage
OmniAccess Wireless System described in About the Alcatel OmniAccess
Wireless System in the Alcatel OmniAccess Wireless Product Guide does
not support signal-to-noise ratio coverage reporting.
Time in days, hours and minutes since the last reboot. Generates a report
with Up Time information. Refer to
Monitor Access Points > <name>
This is the user-assigned name of the OmniAccess AP 1200 or 1250.
Media Access Control address of the OmniAccess AP 1200 or 1250.
IP address of the OmniAccess AP 1200 or 1250.
Displays the administration state of the OmniAccess AP 1200 or 1250 of
either enabled or disabled.
Displays the OmniAccess AP 1200 or 1250 Monitor mode (monitor for
rogue access points without allowing clients to associate), local or
OmniAccess AP 1200R or 1250R.
In order for Alcatel OmniAccess Remote Edge Access Points
Note:
(OmniAccess 1200R APs) to operate correctly, this parameter must be set
to OmniAccess AP 1200R or 1250R.
The operational status of the OmniAccess AP 1200 or 1250 comes up as
either registered or not registered automatically by the Alcatel
OmniAccess Switch or Appliance.
The Alcatel OmniAccess Switch or Appliance to which the OmniAccess AP
1200 or 1250 is registered. Click to display the parameters of the regis-
tered Alcatel OmniAccess Switch or Appliance. Refer to
> <IPaddr> > Summary.
Results
(SNR). Note that the Standalone WPS Alcatel
Monitor Access Points > Up
Configure AP
Description
Monitor Access Points > <name>
Monitor
Time.
Template.
Monitor Switches
