Alcatel OmniAccess Wireless System 2.1 Product Manual page 460

Table -
Traffic Statistics (Continued)
Parameter
Packets
(1519-1530
Octets)
Packets
(> 1530 Octets)
Maximum Info size allowed - The maximum size of the Info (non-MAC) field that this port receives
or transmits.
Table -
Successful Packets
Parameter
Total
Unicast Packets
Multicast Packets
Broadcast Packets
Table -
Protocol Statistics
Parameter
BPDUs
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 11
Received Description
The total number of packets (including
bad packets) received that were
between 1519 and 1530 octets in
length inclusive (excluding framing bits
but including FCS octets).
The total number of packets received
that were longer than 1530 octets
(excluding framing bits, but including
FCS octets) and were otherwise well
formed.
Received Description
The total number of packets received
that were without errors.
The number of subnetwork-unicast
packets delivered to a higher-layer
protocol.
The total number of good packets
received that were directed to a
multicast address. Note that this
number does not include packets
directed to the broadcast address.
The total number of good packets
received that were directed to the
broadcast address.
Received Description
The count of BPDU's (Bridge Protocol
Data Units) received in the spanning
tree layer.
Transmitted Description
The total number of packets
(including bad packets) received that
were between 1519 and 1530 octets
in length inclusive (excluding
framing bits but including FCS
octets).
The total number of packets trans-
mitted that were longer than 1530
octets (excluding framing bits, but
including FCS octets) and were
otherwise well formed.
Transmitted Description
The number of frames that have
been transmitted by this port to its
segment.
The total number of packets that
higher-level protocols requested be
transmitted to a subnetwork-unicast
address, including those that were
discarded or not sent.
The total number of packets that
higher-level protocols requested be
transmitted to a Multicast address,
including those that were discarded
or not sent.
The total number of packets that
higher-level protocols requested be
transmitted to the Broadcast
address, including those that were
discarded or not sent.
Transmitted Description
The count of BPDU's (Bridge Protocol
Data Units) transmitted from the
spanning tree layer.
Ports > Statistics
