Step 1: Collecting Required Tools and Information

Alcatel OmniAccess Switch or Appliance Hardware

•
Alcatel OmniAccess Switch or Appliance (ships with factory-supplied power cord and mounting
hardware).
•
Network, Alcatel OmniAccess Operating System Service network, and Access Point cables, as
required.

CLI Console

CLI Console
•
VT-100 terminal emulator on CLI Console laptop or palmtop.
•
Null modem serial cable to connect CLI Console and Alcatel OmniAccess Switch or Appliance
DB-9 Console port.

Local TFTP Server

•
Required for error-free Alcatel OmniAccess Operating System software updates. (Contact
Technical Support for software updates.)
Note:
TFTP servers cannot run on the same workstation as the ACS Software, because the
ACS Software and the third-party TFTP servers use the same communication port.

Initial System Configuration Information

•
Obtain the following initial configuration parameters from the wireless LAN/network planner:
-
System (Alcatel OmniAccess Switch or Appliance) name.
-
Administrative user name and password. (Default Administrative user name and
password are admin and admin, respectively.)
Note:
subnets.
-
Service-Port Interface IP Address configuration protocol (none or DHCP). (Refer to the
third figure in the
-
If Service port configuration protocol =
Address and Service Port netmask.
-
Management Interface (DS Port, or Network Interface Port) IP Address. (Refer to the
third figure in the
-
Management Interface netmask.
-
Management Interface default router IP address.
-
VLAN identifier, if the Management Interface is assigned to a VLAN, or '0' for an
untagged VLAN.
-
Distribution System Physical Port number:
* 4012: 1 - 12 for front panel or 13 for GigE port
* 4024: 1 -24 for front panel or 25 for GigE port
* 4102: 1 for either front panel GigE port
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide
Local TFTP Server
The ACS Software uses an integral TFTP server. This means that third-party
The Service-Port Interface and Management Interface MUST be on different
Overview for the Service port location.)
Overview for the Distribution System port locations.)
Step 1: Collecting Required Tools and Information
Alcatel OmniAccess Switch or Appliance Hardware
Initial System Configuration Information
, Service Port (front-panel Service port) IP
none
Step 1: Collecting Required Tools and Information
