Telnet-Ssh Configuration - Alcatel OmniAccess Wireless System 2.1 Product Manual

-
Certificate File Name: The Web Administration Certificate filename in encrypted .PEM
(Privacy Enhanced Mail) format.
-
Certificate Password: To decrypt the SSL Web Admin Certificate, enter the SSL
certificate password.
Click Apply and Yes to download the SSL Web Admin Certificate. The Alcatel OmniAccess
Operating System informs you of the file transfer and the Certificate installation progress.
The SSL password decrypts the certificate, and the certificate is used for Secure Web Mode access
when activated.
Note:
the SSL Certificate is changed.
Command Buttons
•
Apply: Data or a Download SSL Certificate request is sent to the Alcatel OmniAccess Switch or
Appliance and made to take effect, but the result is not preserved across a power cycle; these
parameters are stored temporarily in volatile RAM.
•
Delete Certificate: Instruct the Alcatel OmniAccess Operating System to delete the current
SSL Certificate.
•
Regenerate Certificate: Instruct the Alcatel OmniAccess Operating System to generate a new
SSL Certificate to replace any existing Certificate; the Alcatel OmniAccess Switch Web Interface
displays the
Successfully Generated SSL Web Admin Certificate
•
Help: Request that the help page be displayed in a new browser window.

Telnet-SSH Configuration

Use MANAGEMENT/Telnet-SSH to navigate to this page.
Use this page to modify Telnet accessibility to the Alcatel OmniAccess Switch or Appliance.
•
Telnet Login Timeout (minutes): This object indicates the number of minutes a Telnet
session is allowed to remain inactive before being logged off. A zero means there is no timeout.
May be specified as a number from 0 to 160. The factory default is 5.
•
Maximum Number of Telnet Sessions: Selectable from a pulldown menus for values of from
0 to 5. This object indicates the number of simultaneous Telnet sessions allowed. The factory
default is 5.
•
Allow New Telnet Sessions: Indicates that new Telnet sessions are not allowed on the DS
Port when set to no. The factory default value is no.
Note:
and the Service port using the Allow New Telnet Sessions parameter.
•
Allow New SSH Sessions: Indicates that new Secure Shell Telnet sessions are not allowed
when set to no. The factory default value is yes.
Command Buttons
•
Apply: Data is sent to the Alcatel OmniAccess Switch or Appliance and made to take effect, but
not preserved across a power cycle; these parameters are stored temporarily in volatile RAM.
•
Help: Request that the help page be displayed in a new browser window.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 117
The Alcatel OmniAccess Switch or Appliance must be rebooted with save after
Telnet-SSH Configuration
New Telnet sessions are allowed or disallowed on both the DS (network) port
message when done.
Telnet-SSH Configuration
