8.
Define the RF characteristics of each wall on the floor plan:
A.
Use the Select tool to select a wall or walls.
B.
Use the Select Wall Type tool to assign characteristics to the selected wall:
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 11
Heavy Wall for metal and concrete walls and external building walls.
Light Wall for sheetrock/drywall walls, regardless if they are made with metal
or wood studs.
Heavy Door for metal doors.
Light Door for wood or composite doors.
Cubicle for cubicle walls constructed with metal or foil sheets. Note that you
can eliminate cubicle walls with no metal or foil sheets, and those cubicle walls
under four feet (120 cm) tall.
Glass for tinted, colored and/or leaded glass. Note that you can eliminate
segments that include clear, unleaded glass.
Perimeter for building exterior walls.
Using the ACS Floor Plan Editor
