Switch Menu Bar Selection
•
Wireless Menu Bar Selection
•
Security Menu Bar Selection
•
Management Menu Bar Button
•
Commands Menu Bar Selection
Selector Area
Selector Area
The selector area allows you to select a new configuration panel under the menu area that you have
selected. You may select a single choice from several available for data to be displayed or configured.
The selector area options vary based on the menu you select.
Main Data Page
Main Data Page
The main data page depends on what information the menu requires. Input fields are of two basic
types:
•
Text Fields into which data may be entered using the keyboard.
•
Pulldowns from which one of several options may be chosen.
Input fields are black text on a white background. When you enter or select data, it does not go to the
Alcatel OmniAccess Switch or Appliance, but is saved in the field until you click the Apply button. There
may be fields that contain buttons. Selecting a button does take immediate effect. Data may also be
displayed.
Note:
button when you press the enter key while in an input field. On most menus this
triggers the apply function.
Administrative Tools
Administrative Tools
This area provides shortcuts to Administration functions used on a regular basis when configuring an
Alcatel OmniAccess Switch or Appliance through the Alcatel OmniAccess Switch Web Interface.
•
Save Configuration: Data is saved to the Alcatel OmniAccess Switch or Appliance in
non-volatile RAM (NVRAM) and is preserved in the event of a power cycle. If you reboot the
Alcatel OmniAccess Switch or Appliance, all applied changes are lost unless the configuration
has been saved. Click on the Save button to save the current configuration.
•
Ping: Send a Ping to a network element.
This pop-up window allows the you to tell the Alcatel OmniAccess Switch or Appliance to send a
Ping request to a specified IP address. This can help you determine if there is connectivity
between the Alcatel OmniAccess Switch or Appliance and a particular IP station. Once the
operator clicks the Submit button, three pings are sent and the results of the ping are displayed
in the pop-up. If a reply to the ping is not received, it shows No Reply Received from IP
xxx.xxx.xxx.xxx, otherwise it shows Reply received from IP xxx.xxx.xxx.xxx: (send count = 3,
receive count = n).
•
Logout: Exit the current Alcatel OmniAccess Switch Web Interface session.
Button Area
Button Area
At the right side of the main data area are command buttons to apply or refresh the data displayed in
the main data area or request a help window.
Buttons take immediate effect when you select them and information goes to the Alcatel OmniAccess
Switch or Appliance about the state of the menu at that time. The most commonly used buttons are:
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide
Microsoft Internet Explorer generates a submit action on the next available
