DO NOT MOUNT OmniAccess AP 1200 or 1250 ANTENNAS
WITHIN ONE METER (3 FT.) OF ANY METAL OBSTRUCTIONS.
THE RF WAVES FROM OmniAccess AP Access Points ARE
BLOCKED AND/OR REFLECTED BY METAL OBJECTS, such as
metal HVAC ducts, conduit, pipes, bookcases, elevator shafts,
stairwells, and metal walls. REFER TO THE OmniAccess AP 1200
or 1250 Deployment Guide BEFORE MOUNTING OmniAccess AP
Access Points NEAR METAL OBSTRUCTIONS.
•
WHEN MOUNTING OmniAccess AP Access Points IN THE
CORNER OF A RIGHT-ANGLE HALLWAY INTERSECTION, MOUNT
THE OmniAccess AP 1200 or 1250 AT A 45-DEGREE ANGLE TO
THE TWO HALLWAYS. The OmniAccess AP 1200 or 1250
internal antennas are not omnidirectional, and cover a larger
area when mounted this way.
