Configure/Templates Menu Bar Selection; Configure Ap Template; Configure Radio Template - Alcatel OmniAccess Wireless System 2.1 Product Manual

•
Access Level (read only): Read Write or Read Only.

CONFIGURE/TEMPLATES MENU BAR SELECTION

This menu bar selection provides access to the Alcatel OmniAccess Switch or Appliance templates
summary details. Use the selector area to access and configure the respective templates details.
Making this selection from the menu bar displays

Configure AP Template

Use CONFIGURE/Templates, then from the left sidebar menu select AP Templates to access this
page.
This page allows you to add a template of access point information that you can apply to one or more
OmniAccess AP Access Points.
Table -
Access Point Parameters
Column
Checkboxes
Location
Primary Switch Name
Admin Status
AP Mode
Stats Collection Period
Mirror Mode
Command Buttons
•
Apply to APs: Click to apply the selected parameters to selected OmniAccess AP Access Points
on the Configure AP Template > Apply to APs
•
Cancel

Configure Radio Template

Use CONFIGURE/Templates, then from the left sidebar menu select Radio Templates to access this
page.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 144
Configure AP Template
Checkmark to select the parameter to apply to one or more OmniAccess
AP Access Points.
Optionally enter the OmniAccess AP 1200 or 1250 location.
Optionally enter the Primary Alcatel OmniAccess Switch or Appliance
name of the OmniAccess AP 1200 or 1250.
Optionally enter the OmniAccess AP 1200 or 1250 administrative status:
Checkmarked = Enabled, Blank = Disabled.
Optionally enter the state of the OmniAccess AP 1200 or 1250 Monitor
mode (monitor for rogue access points without allowing clients to
associate): either local, OmniAccess AP 1200R or 1250R or Monitor.
In order for Alcatel OmniAccess Remote Edge Access Points
Note:
(OmniAccess 1200R APs) to operate correctly, this parameter must be set
to OmniAccess AP 1200R or 1250R.
Optionally enter the collection period in seconds for OmniAccess AP 1200
or 1250 statistics.
Optionally Enable or Disable OmniAccess AP 1200 or 1250 Mirroring
mode, as described in the Alcatel OmniAccess Wireless Product Guide.
Configure Radio Template
CONFIGURE/TEMPLATES MENU BAR SELECTION
CONFIGURE/TEMPLATES MENU BAR SELECTION
Configure NTP Server
Options
page.
Templates.
