Alcatel OmniAccess Wireless System 2.1 Product Manual page 609

Column
Date/Time
Top 5 APs
Top 5 APs
This table contains the following information. Note that the Standalone WPS Alcatel OmniAccess
Wireless System described in About the Alcatel OmniAccess Wireless System in the Alcatel OmniAccess
Wireless Product Guide does not support voice and data clients.
Column
AP Name
Map Location
a Clients
b/g Clients
Total
Most Recent Coverage Holes
Coverage holes are areas where clients cannot receive a signal from the wireless network. When
deploying wireless networks, there is a trade-off between the cost of the initial network deployment
and the percentage of coverage hole areas. A reasonable coverage hole criterion for launch is between
2 and 10 percent. This means that between two and ten test locations out of 100 random test locations
may receive marginal service. After launch, the OmniVista AirView Software identifies these coverage
areas and reports them to the IT manager, allowing the IT manager to fill holes based on user demand.
Note that the Standalone WPS Alcatel OmniAccess Wireless System described in About the Alcatel
OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not support voice
or data clients or detect coverage holes.
This table contains the following information:
•
Access Point: Number of coverage holes found per OmniAccess AP 1200 or 1250. If none were
found, the message "No Coverage Holes Found" appears.
•
Interface: Interface type.
•
Percent: Percentage of coverage are that cannot receive a signal.
Clients
Clients
This graphs associated clients versus time. Note that the Standalone WPS Alcatel OmniAccess Wireless
System described in About the Alcatel OmniAccess Wireless System in the Alcatel OmniAccess Wireless
Product Guide does not support voice or data clients.
Left Sidebar
Left Sidebar
The left side bar for this screen contains the following:
•
Search for Switch by (pulldown):
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 30
Date and Time that the rogue access point was first detected.
This is the name assigned to the OmniAccess AP 1200 or 1250. Click an
Alcatel OmniAccess AP Name to display
User-defined location map. Refer to
Number of 802.11a clients currently associated with the Alcatel
OmniAccess Switch or Appliance.
Number of 802.11b and 802.11g clients currently associated with the
Alcatel OmniAccess Switch or Appliance.
Total number of clients currently associated with the Alcatel OmniAccess
Switch or Appliance.
Most Recent Coverage Holes
Description
Description
Monitor Access Points >
Monitor Maps >
Monitor Network Summary
<name>.
<campus>.
