Configure <Campus> > Edit Building <Building - Alcatel OmniAccess Wireless System 2.1 Product Manual

•
Horizontal Span: Horizontal measurement (left to right) of the graphic rectangle, in feet or
meters.
•
Vertical Span: Vertical measurement (up and down) of the graphic rectangle, in feet or meters.
Note:
select the command Properties from the pulldown.
Command Buttons
•
Place: Fixes the changes on the display.
•
OK: Saves the changes in the database.
•
Cancel: Cancels the operation.
Map Area Display
Use the blue rectangle to position the outdoor area graphic.
Configure <campus> > Edit Building <building>
Use MONITOR/Maps, then click a Campus item in the Name column, click a building name, then from
the Select a command pulldown, select Edit Building to access this page.
This page allows you to edit an existing building on an existing campus.
Building Identification Information
•
Name: The user-defined name of the building.
•
Contact: User-defined contact name.
•
Floors: The number of floors contained in the building.
•
Basements: The number of basements contained in the building.
•
Horizontal Position: Distance from the corner of the graphic rectangle to the left edge of the
campus map, in feet or meters.
•
Vertical Position: Distance from the corner of the graphic rectangle to the top edge of the
campus map, in feet or meters.
•
Horizontal Span: Horizontal measurement (left to right) of the graphic rectangle, in feet or
meters.
•
Vertical Span: Vertical measurement (up and down) of the graphic rectangle, in feet or meters.
Note:
select the command Properties from the pulldown.
Command Buttons
•
Place: Fixes the changes on the display.
•
OK: Saves the changes in the database.
•
Cancel: Cancels the operation.
Campus and Building Graphic
•
To move the blue rectangle on the map, drag the blue rectangle to a desired new location on
the campus.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 192
To change the unit of measurement (feet or meters), select Monitor>Maps and
To change the unit of measurement (feet or meters), select Monitor>Maps and
Configure <campus> > Edit Building <building>
Configure <campus> > Edit Building <building>
