Alcatel OmniAccess Wireless System 2.1 Product Manual page 703

Table -
802.1X Parameters (Continued)
Parameter
Encryption Key
Key Format
The values in these fields and the fields themselves change depending upon the security
Note:
policies selected.
Table -
WPA Parameters
Parameter
802.11 Data Encryption
Type
Key Size
Preshared Key Mode
IPSec Pass through: Available only when VPN Pass through is selected for Layer 3 Security. Displays
the IP Address of the VPN Gateway Address.
Table -
IPSec Parameters (Available only when IPSec is selected under Layer 3 Security)
Parameter
IPSec Authentication
IPSec Encryption
IKE Authentication
IKE Phase1
Lifetime (seconds)
IKE Diffle Hellman Group
When you select XAuth Pre Shared Key, the key must be at least eight bytes to interoperate
Note:
with Cisco clients. Other tested clients function with a key of less than eight bytes.
Command Buttons
The buttons displayed depend upon the selection made under security policies.
•
Save
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 124
An alphanumeric (letters and/or numbers) series that enables data to
be encrypted and then decrypted so it can be safely shared among
members of a network. WEP uses an encryption key that automatically
encrypts outgoing wireless data. On the receiving side, the same
encryption key enables the computer to automatically decrypt the
information so it can be read.
ASCII or HEX.
Displays the current Key of the security selected in the Security Policies
area.
Active when there is more than one type of encryption available.
TKIP-MIC.
Enable checkbox.
None, HMAC-MD5, HMAC-SHA1.
DES3, None, AES-CBC, DES.
Displays a radio button for selection of Type (Certificate, Pre-Shared
Key, XAuth Pre-Shared Key) and Key (Note).
Aggressive, Main.
IKE timeout in seconds.
Group 1 (768 bits), Group 2 (1024 bits), Group 3 (1536 bits).
Configure WLAN > New Template
Description
Description
Description
