Alcatel OmniAccess Wireless System 2.1 Product Manual page 660

Table -
MAC Operation Parameters (Continued)
Parameter
Max Rx Lifetime
Table -
Tx Power
Parameter
# Supported Power Levels
Tx Power Level x
Tx Power Configuration
Current Tx Power Level
View Pulldown
•
Select On Demand Statistics and click GO to display
•
Select Operational Parameters and click GO to display
•
Select 802.11 MAC Counters and click GO to display
•
Select View Alarms and click GO to display
•
Select View Events and click GO to display
802.11 MAC Counters
From Monitor Access Points > <name> > <radio
access this page.
This page allows you to view 802.11 MAC Counter information for a single 802.11a or 802.11b Omni-
Access Radio.
Table -
General
Parameter
AP Name
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 81
The MaxReceiveLifetime shall be the elapsed time in TU, after the
initial reception of a fragmented MMPDU or MSDU, after which
further attempts to reassemble the MMPDU or MSDU shall be termi-
nated. The default value is 512.
Five or fewer power levels, depending on operator preference.
Power Level (1, highest through 5, lowest) OmniAccess AP 1200 or
1250 transmit power level (1 = Maximum power allowed per Country
Code setting, 2 = 50% power, 3 = 25% power, 4 = 12.5% power,
and 5 = 6.25% power). Note that the power levels and available
channels are defined by the Country Code setting, and are regulated
on a country by country basis. Refer to Supported Regulatory
Domains in the Alcatel OmniAccess Wireless Product Guide for the
maximum Transmit Power Levels for each country.
Globally controlled or Customized for this OmniAccess AP 1200 or
1250 (Custom or Global).
Displays the operating transmit power level from the transmit power
table.
802.11 MAC Counters
This is the name assigned to the OmniAccess AP 1200 or 1250. Click
to view the OmniAccess AP 1200 or 1250 parameters in
Access Points > Access Point >
Monitor Access Points > <name> > <radio type>
Description
Description
On Demand
Operational
802.11 MAC
Monitor Alarms.
Monitor Alarm > Events.
type>, select 802.11 MAC Counters and click GO to
Description
<name>.
Statistics.
Parameters.
Counters.
Configure
