Configure Maps > Edit Campus <name>
Use MONITOR/Maps, click a Campus name in the Name column, select Edit Campus from the Select
a command pulldown and click GO to access this page.
This page allows you to edit an existing campus. This page consists of two areas:
Campus Information
•
Campus Name: User-defined name of the campus.
•
Contact: User-defined contact name.
•
Image File Name: Name of the file containing the campus map. Use the Browse button to find
the file.
•
Maintain Aspect Ratio: Select this checkbox to maintain the aspect ratio (ratio of horizontal and
vertical pixels) of the map image. Maintaining the aspect ratio prevents visual distortion of the
map.
•
Dimensions (feet/meters):
-
Horizontal: Horizontal measurement (left to right) of the campus as it appears on the
page.
-
Vertical: Vertical measurement (up and down) of the campus as it appears on the page.
Command Buttons
•
OK
•
Cancel
Campus Graphic
The graphic of the current campus.
Sidebar: Maps
•
Search for: All Maps, Campuses, Buildings, Floor Areas, Outdoor Areas, Access Points.
•
Enter name: User-defined name.
•
Search Button.
Configure <campus> > Edit Outdoor Area <name>
Use MONITOR/Maps, click a campus name, click an Outdoor Area name, and select Edit Outdoor
Area to access this page.
This page allows you to edit an existing outdoor area.
•
Name: The user-defined name of the new outdoor area.
•
Contact: The user-defined contact name.
•
Image File: Name of the file containing the outdoor area map. Use the Browse button to find
the file.
•
Horizontal Position: Distance from the corner of the graphic rectangle to the left edge of the
campus map, in feet or meters.
•
Vertical Position: Distance from the corner of the graphic rectangle to the top edge of the
campus map, in feet or meters.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 191
