This page allows you to edit all the existing Mobility Group members' MAC Addresses and
IP Addresses in a text box, and then to cut and paste all the entries from one Alcatel OmniAccess
Switch or Appliance to the other Alcatel OmniAccess Switches and Appliances in the Mobility Group.
You can edit existing entries and/or paste new entries directly into the box. In all cases, leave one
space between the MAC address and IP address on each line.
The text box on this page makes it easy to avoid data-entry errors while copying the Mobility Group
Members List to all the Alcatel OmniAccess Switches and Appliances in the same mobility group:
1.
Notice that the text box starts with the local Alcatel OmniAccess Switch or Appliance MAC
address and IP address.
2.
In the text box, add the MAC addresses and IP addresses for the rest of the Alcatel OmniAccess
Switches and Appliances in the same geographical location (such as a campus or building) you
want to add to the Static Mobility Group.
3.
When you have added all the Alcatel OmniAccess Switch and Appliance MAC addresses and IP
addresses to the Static Mobility Group, you can cut and paste the complete list into the corre-
sponding boxes in the
Alcatel OmniAccess Switch Web Interface pages.
Command Buttons
Back: Return to the previous window.
Apply: Data is sent to the Alcatel OmniAccess Switch or Appliance and made to take effect, but
not preserved across a power cycle; these parameters are stored temporarily in volatile RAM.
Help: Request that the help page be displayed in a new browser window.

Mobility Statistics

Use SWITCH/Mobility Management/Mobility Statistics to navigate to this page.
This page displays the statistics for Mobility Group events, and is divided into three sections: Global
Mobility Statistics, Mobility Initiator Statistics, and Mobility Responder Statistics.
Global Statistics are those that affect all mobility transactions.
Mobility Initiator Statistics are those that are generated by an Alcatel OmniAccess Switch or
Appliance initiating the mobility event.
Mobility Responder Statistics are those generated by an Alcatel OmniAccess Switch or Appliance
responding to a mobility event.
The following tables list parameters and descriptions or each of these Statistics:
Table -
Global Mobility Statistics
Parameter
Rx Errors
Tx Errors
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 44
Mobility Group Member > Edit All
Mobility Statistics
pages in other mobility group member
Generic protocol packet receive errors, such as packet
too short or format incorrect.
Generic protocol packet transmit errors, such as packet
transmission fail.
Description
