Snmp V1/V2C Community > Edit - Alcatel OmniAccess Wireless System 2.1 Product Manual

Table -
SNMP Community Summary
Parameter
Community Name
IP Address
IP Mask
Access Mode
Status
Command Buttons
•
Back: Return to the previous window.
•
Apply: Data is sent to the Alcatel OmniAccess Switch or Appliance and made to take effect, but
not preserved across a power cycle; these parameters are stored temporarily in volatile RAM.
•
Help: Request that the help page be displayed in a new browser window.
SNMP v1/v2c Community > Edit
Use MANAGEMENT/SNMP Communities then Edit to navigate to this page.
Use this page to Enable or Disable an SNMP community profile. All fields are read-only except the
Status field.
Table -
SNMP Community Summary
Parameter
Community Name
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 109
The community string to which this entry grants access. A valid entry is a
case-sensitive alphanumeric string of up to 16 characters. Each row of
this table must contain a unique community name.
An IP address from which this device accepts SNMP packets with the
associated community. The requesting entity's IP address is ANDed with
the Subnet Mask before being compared to the IP Address.
If the Subnet Mask is set to 0.0.0.0, an IP Address of 0.0.0.0
Note:
matches all IP addresses. The default value is 0.0.0.0.
A mask to be ANDed with the requesting entity's IP address before
comparison with IP Address. If the result matches with IP Address then
the address is an authenticated IP address. For example, if the IP Address
= 9.47.128.0 and the corresponding Subnet Mask = 255.255.255.0 a
range of incoming IP addresses would match, that is, the incoming IP
Address could equal 9.47.128.0 - 9.47.128.255. The default value is
0.0.0.0.
The access level for this community string. May be specified by selecting
Read/Write or Read Only from the pulldown.
The status of this community access entry. When this object is set to
enabled, if the Community Name for this row is not unique among all
valid rows, the set request is rejected. Community names may be made
invalid by selecting disable.
SNMP v1/v2c Community > Edit
The community string to which this entry grants access. A valid entry is a
case-sensitive alphanumeric string of up to 16 characters. Each row of
this table must contain a unique community name.
Range
Range
SNMP v1/v2c Community > Edit
